| Model |
KLCLCEM-9060 / 1390 / 1410 / 1610 / 1325 |
| X, Y Cutting Area |
900 x 600, 1300 x 900, 1600 x 1000, 1300 x 2500 |
| Laser Power |
80W / 100W / 130W / 150W / 100W / 130W |
| Travelling Speed |
<500 mm/s |
| Reposition Accuracy |
±0.01 mm |
| Minimum Letter Size |
1 mm (English Font) |
| Power Adjustment |
1% to 100% |
| Maximum Cutting Thickness |
Up to 15 mm Acrylic, Up to 20 mm Acrylic, Up to 25 mm Acrylic |
| Working Table |
Blade and Honeycomb (Optional) |
| Driving System |
Stepper Motor |
| Operating System |
Windows 7 (32/64 Bit), Windows 10 |
| Interface |
USB Interface |
| Supported Format |
BMP, PLT, DST, AI, DXF, etc. |
| Working Voltage |
Single Phase AC220V±10%, 50–60Hz (Required Earthing) |
| Running Environment |
45°C, Humidity 5%–95% (without condensed water) |
| Overall Dimension (L × W × H) |
1420 x 1020 x 980, 1820 x 1320 x 980, 3650 x 1883 x 940 |
| Weight |
250kg, 410kg, 870kg |
| Power Consumption |
3 kW – 10 kW |
